High quality PVC True Union Ball Valve Plain End for irrigation & agriculture. Made in India. Leak proof, durable & corrosion resistant. Best price. Call 9712533344.
| Sr.No. | Part | Qty. | Material |
| 1. | Body | 1 | RPVC |
| 2. | Stem | 1 | RPVC |
| 3. | Ball | 1 | RPVC |
| 4. | Cover | 1 | RPVC |
| 5. | Seats | 2 | PTFE/HDPE |
| 6. | Screw end connector | 1 | RPVC |
| 7. | Cover Gasket | 1 | Neoprene or All type of Rubber |
| 8. | Stem “O” Ring Seal | 1 | Neoprene or All type of Rubber |
| 9. | Handle | 1 | RPVC / PP |
| Construction | Multy Piece Body |
| Design | Union Assembly |
| Size Range | 15,20,25,32,40,50, 65, 80 & 100 mm. |
| Max working temp. | 90°C (Consistently) |
| Gasket/Stem Seal | Neoprene |
| Test Pressure | 10kg./cm² |
| Parameter | Details |
|---|---|
| Product Name | PVC True Union Ball Valve |
| Brand | Poonam Industries® |
| Material | Premium PVC (Virgin Grade) |
| Size Range | ½” (15mm) to 4” (110mm) |
| End Connection | Threaded / Socket (True Union Type) |
| Pressure Rating | PN10 (Up to 10 kg/cm²) |
| Port Type | Standard Bore / Full Bore |
| Handle Color | Blue / Red (Optional) |
| Body Color | Gray / White |
| Working Temperature | Up to 50°C |
| Automation Grade | Manual (Quarter-Turn Operation) |
| Application | Irrigation, Water Supply, Drip Systems, Sprinkler Networks |
| Country of Origin | Made in India |
Drip Irrigation Systems
Sprinkler Irrigation Networks
Agricultural Water Supply Lines
Nursery & Greenhouse Piping
Fertilizer & Chemical Dosing Lines
Residential & Commercial Water Distribution
Industrial Fluid Handling (Non-Corrosive)
At Poonam Industries, every valve undergoes stringent quality testing to ensure durability, pressure integrity, and leak-proof performance. Our products are trusted by farmers, contractors, and engineers across India for their consistent quality and reliable after-sales support.
✅ Made in India – High-quality local manufacturing
✅ Complete size range – ½” to 4” available
✅ Competitive pricing – Factory-direct rates
✅ Reliable after-sales service and support
✅ Tested for durability and long life
✅ Sustainable & eco-friendly solution
RPVC True Union Ball Valve Plain End | RPVC True Union Ball Valve Irrigation | PVC True Union Ball Valve Manufacturer |
|---|---|---|
High quality product. Plain End PVC True Union Ball Valve | High quality product. Irrigation PVC True Union Ball Valve | Manufactured in India. Manufacturer India – PVC True Union Ball Valve |
Agricultural PVC True Union Ball Valve | Irrigation PVC True Union Ball Valve | RPVC True Union Ball Valve |
High quality product. Agricultural Farming – PVC True Union Ball Valve | High quality product. Irrigation Water – PVC True Union Ball Valve | Manufactured in India. PVC True Union Ball Valve – Made in India |
Industrial PVC True Union Ball Valve | Drip Irrigation RPVC True Union Ball Valve | High Quality PVC True Union Ball Valve |
High quality product. Industrial Heavy Duty – PVC True Union Ball Valve | High quality product. Drip Irrigation – PVC True Union Ball Valve | Manufactured in India. High Quality Premium – PVC True Union Ball Valve |
Heavy Duty PVC True Union Ball Valve | Best PVC True Union Ball Valve | PVC True Union Ball Valve India |
High quality product. Heavy Duty Strong – PVC True Union Ball Valve | High quality product. Best Top Quality – PVC True Union Ball Valve | PVC True Union Ball Valve IndiaManufactured in India. India – Made in India – PVC True Union Ball Valve |
PVC True Union Ball Valve Ahmedabad | PVC True Union Ball Valve Gujarat | PVC True Union Ball Valve Dealer |
High quality product. Ahmedabad Gujarat – PVC True Union Ball Valve | High quality product. Gujarat India – PVC True Union Ball Valve | PVC True Union Ball Valve DealerManufactured in India. Dealer Distributor – PVC True Union Ball Valve |
RPVC True Union Ball Valve Distributor | PVC True Union Ball Valve Company | PVC True Union Ball Valve Price |
RPVC True Union Ball Valve DistributorHigh quality product. Distributor Wholesale – PVC True Union Ball Valve | PVC True Union Ball Valve Company
High quality product. Company – Poonam Industries – PVC True Union Ball Valve | PVC True Union Ball Valve Price
Manufactured in India. Price – Best Price – PVC True Union Ball Valve |
PVC True Union Ball Valve Supplier | PVC True Union Ball Valve Exporter | PP Union Type Assembly Manufacturer India |
PVC True Union Ball Valve SupplierHigh quality product. Supplier Trusted – PVC True Union Ball Valve | PVC True Union Ball Valve ExporterHigh quality product. Exporter Worldwide – PVC True Union Ball Valve | PP Union Type Assembly Manufacturer IndiaManufactured in India. Manufacturer Made in India |
FAQ – PVC True Union Ball Valve (Plain End)
A PVC True Union Ball Valve is a type of quarter-turn valve used to control the flow of water and other fluids in piping systems. The "True Union" design allows the valve to be easily removed from the pipeline for maintenance or replacement without disturbing the existing pipe connections. It features a plain end connection type for socket/welding joint installations.
Plain End means the valve ends are smooth and straight, without any threads. These ends are designed for socket welding or solvent cement jointing (using PVC adhesive) directly into the pipe. This provides a strong, permanent, and leak-proof connection.
We offer a complete size range from ½ inch (15mm) to 4 inch (110mm). All sizes are available in Plain End connection type.
| Size (Inch) | Size (mm) |
|---|---|
| ½” | 15 mm |
| ¾” | 20 mm |
| 1” | 25 mm |
| 1¼” | 32 mm |
| 1½” | 40 mm |
| 2” | 50 mm |
| 2½” | 63 mm |
| 3” | 75 mm |
| 4” | 110 mm |
Our valves are made from high-grade virgin PVC (Polyvinyl Chloride) material. It is strong, durable, UV-stabilized, and resistant to corrosion, chemicals, fertilizers, and weather conditions – making it ideal for outdoor agricultural use.
Yes, absolutely. Our PVC True Union Ball Valves are specially designed for:
Drip irrigation systems
Sprinkler networks
Agricultural water supply lines
Nursery and greenhouse piping
Fertilizer and chemical dosing lines
Yes. Our valves are precision-engineered with a high-quality ball and EPDM/PTFE seat design, ensuring a 100% leak-proof seal even under high-pressure conditions.
Our PVC True Union Ball Valves are rated for PN10, which means they can safely handle working pressures up to 10 kg/cm² (approximately 5 to 10 kg) depending on the size and application.
These valves are designed to perform efficiently at temperatures up to 50°C to 60°C. They are suitable for normal water and agricultural fluid applications.
Yes. The Plain End design allows for quick and easy installation using PVC solvent cement. The True Union feature also allows the valve body to be removed for servicing without cutting the pipeline.
Yes. PVC material offers excellent resistance to:
Corrosion
Rust
Chemicals like fertilizers and pesticides
UV radiation (sunlight)
Weathering and aging
Yes. All our PVC True Union Ball Valves are proudly manufactured in India at our state-of-the-art facility, ensuring premium quality and competitive pricing.
Yes. Poonam Industries provides reliable after-sales support, including:
Technical guidance
Replacement assistance
Quick response to queries
Bulk order support
Yes. We offer bulk ordering options and can also customize valve specifications as per your project requirements. Contact us for detailed discussions.
We offer handles in Blue and Red colors. Standard body color is Gray or White, depending on the product batch.
Maintenance is very simple:
Regularly check for any debris or blockages.
Clean the ball and seat if the valve becomes stiff.
The True Union design allows easy disassembly for cleaning without removing the entire pipe.
| Feature | Plain End | Threaded End |
|---|---|---|
| Connection | Solvent cement / socket welding | Screw / thread fitting |
| Installation | Permanent joint | Removable joint |
| Leak-proof | Very high | High (with thread sealant) |
| Application | Permanent pipelines | Temporary or frequently dismantled systems |
Yes. Our PVC material is non-toxic and safe for potable (drinking) water applications, subject to local plumbing standards.
We offer a manufacturing defect warranty on all our products. For detailed warranty terms, please contact our sales team.
You can place an order by:
📞 Calling: 9712533344
📱 WhatsApp: 9427957138
Or visiting our dealer/distributor network across India.
Yes. We export our PVC True Union Ball Valves to various countries. Our products meet international quality standards and are trusted by global buyers.
